SPIRE CPU chladič CoolReef Pro PWM, AM2/939/940 AMD Cooler, 1200~3500RPM, 15.0~41.0dBA, 56.46CFM

SPIRE CPU chladič CoolReef Pro PWM, AM2/939/940 AMD Cooler, 1200~3500RPM, 15.0~41.0dBA, 56.46CFM
SPIRE CPU chladič CoolReef Pro PWM, AM2/939/940 AMD Cooler, 1200~3500RPM, 15.0~41.0dBA, 56.46CFM
SPIRE CPU chladič CoolReef Pro PWM, AM2/939/940 AMD Cooler, 1200~3500RPM, 15.0~41.0dBA, 56.46CFM
SPIRE CPU chladič CoolReef Pro PWM, AM2/939/940 AMD Cooler, 1200~3500RPM, 15.0~41.0dBA, 56.46CFM
SPIRE CPU chladič CoolReef Pro PWM, AM2/939/940 AMD Cooler, 1200~3500RPM, 15.0~41.0dBA, 56.46CFM
SPIRE CPU chladič CoolReef Pro PWM, AM2/939/940 AMD Cooler, 1200~3500RPM, 15.0~41.0dBA, 56.46CFM

Cooler type:Active; Cooler utilization:CPU

Your price: the product is no longer available

Price information

Your price excl. SNC:
-
  • Retail price:
    -
  • SNC:
    -
  • AO:
    -
  • Your price inc. sales tax:
    -
Code:
319207
P/N:
SP805S3-PWM
Warranty:
24 Month(s)
Manufacturer:
Spire
Representative in the EU:
EAN:
6943051206325

Particulars

http://www.spire-corp.com/cpu-coolers/coolreef-pro-pwm-sp805s3-pwm/

AM2/939/940 AMD Cooler, Aluminum Heat-Sink, 80mm reversed-fan, Sleeve Bearing, 1200~3500RPM, 15.0~41.0dBA, 56.46CFM, 0.337C/W, Tool-free Installation

Features:

  • Aluminum CNC heat-sink

  • 95x25mm silent DC fan

  • Clip-Mount secure AMD retention

  • Retail packed for save transport

  • S420 Thermal compound included

  • Applicable to AM2/AM3/FM1/FM2

Specifications:

Unit Weight

238g

Unit Dimension (cm)

7.7 x 8.5 x 3.4

Accessories

CoolReef Pro PWM

Air Flow (CFM)

56.46

Application
  • AMD Athlon X2 (AM2/AM2+)

  • AMD FM1 (AMD Radeon HD 6530D)

  • AMD FM2

  • AMD Phenom (AM2/AM2+)

  • AMD Phenom II (AM2/AM3)

  • AMD Sempron 3600+

  • AM3+

Bearing Type

Sleeve Bearing

Certification

CE/ROHS

Connectors

4 PIN PWM Molex 2510

Fan Size (cm)

9,5 x 9,5 x 2,5

Fan Type

12VDC

Fits Socket Types

AMD

AMD

AM2,AM3,FM1,FM2

Life Expectancy (HRS)

30000

Material

AL

Noise Level (dBA)

15 ~ 41

Number Of Fans (Pre-Installed)

1

Operating Temperature (°C) From

-10

Operating Temperature (°C) To

70

Options

Heatpipes

Packaging Type

Brown box

Rated Current (A)

0.36

Rated Power (W)

4.32

Rated Speed (RPM) +/- 10%

1200 ~ 3500

Static Pressure mmH2O

4.04

Storage Temperature (°C) From

-40

Storage Temperature (°C) To

70

Thermal Design Power (W)

100

Thermal Resistance

0.337

Voltage DC (INPUT)

12 V
